Features Remote control! The suppressor can be turned on remotely using the radio channel control panel. The remote control operation distance is up to 30 meters. Please note that it is possible to switch off the suppressor only manually, since during the operation of the suppressor the remote control will also be blocked.   Suppression of the entire range of wireless Internet. The device blocks any data transfer through the mobile Internet 4G LTE L1 / Mobile and 3G, as well as Wi-Fi and Bluetooth computer networks.   Cell phone blocking makes it impossible to transfer data via GSM and 3G network using SMS and MMS messages and voice calls, and also prevents unauthorized remote connection to a mobile phone for wiretapping.   Suppression of satellite navigation GPS 1500 MHz. Allows you to block the operation of satellite tracking devices, such as auto tracker, navigator and GPS beacon, which determine your location.   Autonomous work. The suppressor is equipped with two built-in batteries that allow the device to work autonomously for up to 1.5 hours, which makes the device mobile for use in on-site negotiations and meetings.   Forced cooling. The suppressor is equipped with two built-in coolers and air holes on the case, which protects the device from overheating and failure.   Silent work. In the suppression mode, the device works quietly, so it won’t attract the attention of third parties.   The range of the block is up to 15 meters. Allows you to suppress the radio frequencies of cellular communications and mobile Internet in a small office or car during negotiations.   Continuous work using 220V network. It allows the suppressor to work continuously, not limited to the battery charge and without changing the radio frequency blocking radius.   Compact size. Due to its relatively small size, the suppressor can be freely placed in a business portfolio or in interior items.

The propagation radius of interference reaches 15 meters, but can vary up or down - this directly depends on the power and proximity of the Wi-Fi access point, LTE 4G provider repeaters and GSM and 3G cellular base stations.

The suppressor works autonomously powered by the built-in battery for up to 1.5 hours or continuously powered by the 220V network through the 12V adapter.

Area of use

«Terminator 10XL - pult» suppressor is an excellent protector of confidential information of your business and personal life. The device blocks almost the entire transmission of information over wireless networks of mobile Internet and cellular communications GSM and 3G. The suppressor of 31 communications standard has a fairly compact size, can be placed in the meeting room or office discreetly. You can enable the suppression using the remote radio channel control from a distance of up to 30 meters. When on business trips, the suppressor can be placed in a small briefcase.



Principle of operation

The multi-frequency suppressor «Terminator 10XL - pult» blocks the operation of the entire range of mobile Internet 3G, Wi-Fi, LTE 4G L1 and 4G Mobile and GSM cellular communications. The device operates using 220V network or autonomously powered by a built-in battery. The radio frequency suppression radius can reach 15 meters.

Technical specifications

31 suppression standards:

Frequency Range: 925-960 MHz

Standards:

• GPRS (downlink): 925-960 MHz
• EDGE (downlink): 925-960 MHz
• UMTS (downlink): 925-960 MHz
• GSM-900 (downlink): 925-960 MHz
• EGSM (downlink): 925-960 MHz

Frequency range: 1805-1880 MHz

Standards:

• EDGE (downlink): 1805-1880 MHz
• GPRS (downlink): 1805-1880 MHz
• HSUPA (downlink ): 1805-1880 MHz
• DCS (downlink): 1805-1880 MHz
• LTE B3 (downlink): 1805-1880 MHz
• GSM-1800 (downlink): 1805-1880 MHz

Frequency range: 790-826 MHz

Standards:

• AMPS / D-AMPS : 790-826 MHz
• LTE B20 (downlink): 791-821 MHz

Frequency range: 850-894 MHz

Standards:

• LTE B5 (downlink): 869-894 MHz
• GSM-850 (downlink): 869-894 MHz
• ZigBee: 868 MHz LPD868 : 868 MHz
• CDMA: 850-890 MHz

Frequency range: 2110-2170 MHz

Standards:

• IMT-MC (downlink): 2110-2170 MHz
• W-CDMA (downlink): 2110-2170 MHz
• HSDPA (downlink): 2110-2170 MHz
• HSPA + (downlink): 2110-2170 MHz

Frequency range: 2400-2500 MHz

Standards:

• Wi-Fi: 2400-2500 MHz
• Bluetooth: 2450-2485 MHz
• RC 2.4G (video signal): 2400-2500 MHz

Frequency range: 1570-1610 MHz

Standards:

• GLONASS L1 (1st generation): 1602 MHz
• GLONASS L1 (2nd generation): 1600.995 MHz
• GPS L1: 1575.42 MHz
• GLONASS L1 (3rd generation): 1575.42 MHz

Frequency range: 2620-2690 MHz

Standards:

• WiMax: 2620-2690 MHz
• LTE B7 (downlink): 2620-2690 MHz



• Total output power: 4 W;
• Radius of suppression: from 5 to 15 meters
• Remote control: yes
• Radius of operation of the remote control: up to 30 meters without barriers
• Autonomous operation: up to 1.5 hours;
• Battery, 2pcs: 12V, 1800mAh (each);
• Charging time: 9 hours;
• Power via adapter: 12V;
• Operation temperature: from - 10 to + 55 C;
• Forced cooling: cooler 2 pcs.;
• Dimensions with antennas: 265x98x58 mm;
• Weight: 660 grams.

Package content

1. «Terminator 10XL - pult» suppressor - 1 pc.
2. 12V power adapter - 1 pc.
3. Instruction manual - 1 pc.
