Features

• Scrambled speech intelligibility no more than 3-5% of words. This means that when listening to encrypted speech with an unauthorized connection to your phone during negotiations, the probability of understanding the essence of the conversation is possible by a maximum of 3-5%.

• Four encryption modes to choose from. The Guard Bluetooth scrambler has 4 software modes. During negotiations by cell phone, the interlocutors can switch from mode to mode, thereby most effectively protecting themselves third parties’ wiretapping.

Bluetooth connection between the phone and the scrambler. Wireless connection of the device with a mobile phone is more convenient for using a call protection device through a cell phone.   Scrambler coding uses frequency inversion. When scrambling during negotiations, there is a frequency shift of 6 decibels in different directions, which ensures the encryption of the interlocutors speech.   Universal headphone jack. The Guard Bluetooth scrambler has a standard audio jack for using 3.5 mm jack headphones.   Powered by replaceable batteries. The scrambler runs on a 9V battery, which can be replaced at any time.

Technical characteristics

• Coding principle: inversion of the sound spectrum;
• Wireless connection: Bluetooth;
• Key formation: static;
• Total number of the algorithm combinations: 4 combinations;
• Number of inversion frequency changes: 4 frequencies;
• Key sequence length: 16 bits;
• Communication channel: full duplex;
• Descrambled speech intelligibility: 95%;
• Sound inversion band: from 280 Hz to 3140Hz;
• Pitch bias during scrambling of 6dB audio stream per octave;
• Inversion frequency range: from 44.336kHz to 184.734kHz;
• Output impedance: from 300 to 500 kOhm;
• Power supply: 9V;
• Current Consumption mA: 70 mA;
• Indication: LED;
• Case material: plastic, aluminum;
• Dimensions: 134x70x24 mm;
• Weight: 100 grams.

Package

1. Scrambler - 2 pcs.
2. Headset - 1 pc.
3. Battery - 2 pcs.
